Gluing machine for latex and water based adhesives, particularly suitable for combining pieces inleather and synthetic materials and all very soft thin materials, (uppers and linings, parts for handbags, suitcases and general leather goods).
All components in contact with the adhesive are heat coated with P.T.F.E. for easy rapid cleaning and can be easily removed without using tools; the gluing tank is in stainless steel coated with P.T.F.E. and supplied from a removable 5 litre container.
This open arm machine is equipped with a guide for gluing piece edges and other additional components are available for special requirements on demand.
Hard and soft rollers 200-350-500 mm are available.
Possibility of mounting an electronic speed variator.
Additional information
Tipi di Adesivi
Water Based
Applicatori
Roller applicators from bottom side, Roller applicators from top side
Technical Data
ECOL RANGE ROLLERS mm. 500 WIDTH cm. 93 LENGTH cm. 35 HEIGHT cm. 80 DEPTH K.g 54 POWER MOTOR HP 0,25
Photo Gallery
Applications
Video Gallery
OMAV Mod. ECOL 500 (water based) Coating example on agenda’s materails.
OMAV Mod. ECOL 200 test with very thin materials Coating example with very thin materials.
OMAV unmounting/mounting Unmounting procedure for cleaning.
Description
Gluing machine for latex and water based adhesives, particularly suitable for combining pieces inleather and synthetic materials and all very soft thin materials, (uppers and linings, parts for handbags, suitcases and general leather goods).
All components in contact with the adhesive are heat coated with P.T.F.E. for easy rapid cleaning and can be easily removed without using tools; the gluing tank is in stainless steel coated with P.T.F.E. and supplied from a removable 5 litre container.
This open arm machine is equipped with a guide for gluing piece edges and other additional components are available for special requirements on demand.
Hard and soft rollers 200-350-500 mm are available.
Possibility of mounting an electronic speed variator.
Additional information
Water Based
Roller applicators from bottom side, Roller applicators from top side
Technical Data
ECOL RANGE ROLLERS mm. 500
WIDTH cm. 93
LENGTH cm. 35
HEIGHT cm. 80
DEPTH K.g 54
POWER MOTOR HP 0,25
Photo Gallery
Applications
Video Gallery
OMAV Mod. ECOL 500 (water based)
Coating example on agenda’s materails.
OMAV Mod. ECOL 200 test with very thin materials
Coating example with very thin materials.
OMAV unmounting/mounting
Unmounting procedure for cleaning.
